H8506 Handheld Airborne Particle Counters
0.5 – 25 µm @ 0.1 CFM
The Airy Technology® 8506 Handheld Particle Counter measures 0.5 to 25.0 μm with a flow rate of 0.1 CFM (2.83 LPM).
Easy to configure, this instrument displays up to 6 user-selectable size channels as well as temperature and relative humidity. View data and generate ISO 14644-1, EU GMP Annex 1 or FS 209E reports on screen or via printer, USB key, real time through its versatile output options or export to Particles Plus® data-download software. Particles Plus® counters can be controlled and monitored remotely via web browser. The H8506 also has a mass concentration mode that approximates density in μg/m³.
All Airy Technology® counters meet ISO 21501-4 and JIS B9921. The H8506 ensures compliance with an on-board pulse height analyzer.
| Measures 0.5 μm to 25.0 μm |
| 0.1 CFM (2.83 LPM) flow rate |
| Long-life laser diode technology |
| Measures up to 6 channels of simultaneous data |
| Approximates mass concentration in μg/m³ |
| Integrated handle for one-handed operation |
| Large easy-to-use icon driven color touch screen display |
| Optional temperature and relative humidity probe included |
| Stores up to 45,000 sample records, 1,000 sample locations and 50 recipes |
| Easy configuration and transferable from instrument to instrument |
| Connect using Ethernet, USB or (optional) Wireless 802.11 b/g, RS485 or RS232 |
| Displays and externally prints reports for ISO 14644-1, EU GMP Annex 1 and FS 209E |
| Internal audible alarm |
| User-definable reports |
| User-selectable channel sizes |
| Complies with ISO 21501-4 and JIS B9921 standards |
| Easy to clean and wipe down with minimal particle traps |
| Seamless integration into a facility monitoring system |
| Lightweight high-impact injection molded plastic enclosure |
| 1 year limited warranty. Extended warranties available. |
| Size Range | 0.5 to 25.0 μm |
| Size Channels | Factory calibrated at 0.5, 0.7, 1.0, 3.0, 5.0, 10.0 μm variable binning |
| Flow rates | 2.83 LPM (0.1 CFM) |
| Concentration Limit | 15,000,000 Particles/ft³ @ 5% coincidence loss |
| Battery Run Time | 10 hours |
| Light Source | Long life laser diode |
| Counting Efficiency | 50% @ 0.5 μm; 100% for particles >0.75 μm per JIS |
| Zero Count | <1 count / 60 minutes (<1 particles / 6 ft³). No fault count subtraction. |
| Count Modes | Automatic, manual, real-time meter, cumulative/differential, mass concentration, count or concentration |
| Count Alarms | 1 to 9,999,999 counts |
| Calibration | NIST traceable |
| Display | 4.3″ (10.9 cm) WQVGA (480×272) color touch screen |
| Printer (Optional) | External thermal printer |
| Vacuum Source | Internal pump with automatic flow control |
| Filtered Exhaust | Internal HEPA filter |
| Number of Channels | 6 |
| Custom Size Channels | Calibration for custom size channels available |
| Audible Alarm | Adjustable built-in alarm |
| Battery | Removable Li-ion |
| Battery Recharge Time | 4 hours within instrument (<2 hours with external battery charger) |
| Reports | ISO 14644-1, EU GMP Annex 1, FS 209E |
| Recipes | 50 user-configurable recipes |
| Communication Modes | Ethernet and USB |
| Optional Communication Modes | Wireless 802.11 b/g, RS485 or RS232 |
| Environmental Sensor | Includes temperature and relative humidity probe 32º to 122ºF (0º to 50ºC) ±1ºF (0.5ºC), 15-90% ±2% relative humidity |
| Alarm | Alarms on counts for all particle sizes, low battery, sensor failure, environmental sensors and flow |
| Standards | ISO 21501-4 and JIS B9921 |
| Calibration | Recommended minimum once per year |
| External Surface | High impact injection molded plastic |
| Dimensions (L x W x H) | 10” x 5” x 4.5” (25.4 cm x 12.9 cm x 11.4 cm) includes handle and does not include probes |
| Weight | 2.2 lb (1.0 kg) |
| Accessories | Operating manual on USB flash drive, isokinetic probe, temperature relative humidity sensor, filter, battery, data download software, USB cable, power supply & cable |
| Optional Accessories | Printed manual, carrying case, spare battery, external battery charger, external printer and isokinetic probes |
| Buffer Memory | 45,000 sample records (rotating buffer) including particle count data, environmental data, locations and times. Scrollable on screen or printout |
| Sample Locations | Up to 1,000 locations 20 characters long |
| Sample Time | 1 second to 99 hours |
| Power | 110 to 240 VAC 50/60 Hz universal in-line power supply |
| Operating Conditions | 41º to 104ºF (5º to 40ºC) / 20% to 95% non-condensing |
| Storage Conditions | 32º to 122ºF (0º to 50ºC) / Up to 98% non-condensing |
| Warranty | 1 year limited warranty. Extended warranties available. |
 |  |  |  |
Part Number: AS-99015 | Part Number: EE-80092 | Rechargeable & Removable Part Number: EE-80003A | (For EE-80003A) Part Number: AS-99005A |
 |  |  |  |
Part Number: EE-80014A | 0.1 CFM (2.83 LPM) Part Number: AS-99002 | 0.1 CFM (2.83 LPM) Part Number: AS-99002A | Connector (5 POS) Part Number: EE-79015A |
 |  |  |  |
0.1 CFM (2.83 LPM) Part Number: PS-12041 | 0.1 CFM (2.03 LPM) Part Number: PS-12070 | 0.1 CFM (2.83 LPM) Part Number: PS-12022 | 1/8 (Stainless) Part Number: PS-12005 |
 |
/> |  |  |
Includes 2 Rolls of Paper Part Number: AS-99011 | Single Roll Part Number: AS-99012 | Cleanroom Paper (10 Pack) Part Number: AS-99013 | 15V ~2A 100-240 VAC Part Number: EE-80127 |
 |  |  |  |
USA, Japan, Philippines, Taiwan Part Number: EE-80128 | Europe & Korea Part Number: EE-80129 | UK, Malaysia & Singapore Part Number. EE-80130 | China & Australia Part Number: EE-80131 |
 |  |  |  |
3/8" OD (1/4" ID) Part Number: AS-99019 | 3/8" OD (1/4" ID) Bev-A-Line XX Part Number: AS-99037 | Part Number: MN-24001 | 6ft (1.8m) Part Number: AS-99022 |
 | | ||
User Manual (Printed) Part Number: MN-24001P | Validation Manual Part Number: MN-24002 |
